R44
RAVEN I & CLIPPER I
SPECIFICATIONS
Raven I | Clipper I | |
---|---|---|
Engine | Lycoming O-540, six cylinder, carbureted | Lycoming O-540, six cylinder, carbureted |
Horsepower | Derated to 245 for takeoff and 205 continuous | Derated to 245 for takeoff and 205 continuous |
Maximum Gross Weight | 2400 lb (1089 kg) | 2400 lb (1089 kg) |
Approximate Empty Weight (including oil & standard avionics) | 1450 lb (658 kg) | 1500 lb (680 kg) |
Standard Fuel (29.5 gal) | 177 lb (80 kg) | 177 lb (80 kg) |
Auxiliary Fuel (17.0 gal) | 102 lb (46 kg) | 102 lb (46 kg) |
Pilot, Passengers, and Baggage (with standard fuel) | 773 lb (351 kg) | 723 lb (328 kg) |
Cruise Speed at Maximum Gross Weight | up to 108 kts (200 km/h) | up to 101 kts (187 km/h) |
Maximum Range (no reserve) | approx 300 nm (550 km) | approx 300 nm (550 km) |
Hover Ceiling IGE | 6400 ft @ 2400 lb | 6400 ft @ 2400 lb |
Hover Ceiling OGE | 4000 ft @ 2300 lb | 4000 ft @ 2300 lb |
Rate of Climb | over 1000 fpm | over 1000 fpm |
Maximum Operating Altitude | 14,000 ft | 14,000 ft |
Electrical System | 28 volt | 28 volt |
